VTEC 38291 HDMI - VGA converter (97-38291)

5%
off
$29.00 $27.54(AUD inc. Tax)
Qty
IN STOCK
Help
Bookmark and Share

Related Items

No related items.

HDMI to VGA Converter, HDMI In / VGA Out

  • Connects an HDMI equipped device to a VGA display
  • Supports resolutions up to 1920x1200 including 1080p
  • Direct signal conversion, without scaling
  • Compact dimensions for easy installation and use
  • 2 year warranty

The Lindy HDMI to VGA converter converts signals from an HDMI equipped source into an analogue VGA signal. It supports resolutions up to 1080p and 1920x1200 for PC VGA displays. This allows the connection of modern HDMI capable devices, such as PC’s, notebooks and ultrabooks, to an older VGA display or projector.

The compact dimensions mean it can be easily installed in restricted spaces, allowing for tidy installation behind PCs or for use with laptop workstations. The converter provides connectivity without the expense of having to replace legacy displays and cabling when upgrading to modern PCs or laptops.



Connectors

  • Connector A: HDMI Type A Male
  • Connector B: VGA Female
  • Housing Material: ABS
  • Connector Plating: Nickel
  • Pin Construction: Phosphor Bronze
  • Pin Plating: Nickel
  • Dimensions (approx.) WxDxH: 37x42x14.5mm (1.46x1.65x0.57in)

Cable Construction

  • Length: 100mm (3.94in)
  • Standard: HDMI 1.3
  • Colour: Black
  • Type: Round
  • Jacket Diameter: 4.8mm (0.19in)
  • Jacket Material: PVC
  • Conductor Material: Tinned Copper
  • Conductor Gauge: 30AWG
  • Shielding: Aluminium Braid + Mylar

Specifications

  • Supported Bandwidth: 4.95 Gbps
  • Maximum Resolution: 1920x1200@60Hz 12bit
  • Nominal Attenuation:
  • 300kHz-825MHz <5dB
  • 825MHz-2.475GHz 5dB-12dB
  • 2.475GHz-4.125GHz 12dB-20dB
  • 4.125GHz-5.1GHz 20dB-25dB
  • Operating Temperature: 0°C - 70°C (32°F - 158°F)
  • Storage Temperature: -10°C - 80°C (14°F - 176°F)



No accessories for this product.
