LINDY 42701 USB Fibre hybrid 50m USB3.2 (97-42701)

    50m Hybrid USB 3.2 Gen 1 Cable
    Supports transfer rates up to 5Gbps
    Low RFI/EMI for sensitive environments
    Plug & Play installation
    2 year warranty



The Lindy Hybrid USB 3.2 Gen 1 Cable extends a USB port by 50m, far longer than is possible with standard or active copper cables, whilst retaining SuperSpeed transfer rates of up to 5Gbps (backwards compatible with USB 2.0/1.1/1.0 devices).

A lighter and more flexible construction makes this cable simple to install with cable trays and through conduits, whilst low RFI/EMI ensures that the cable can be installed in the most sensitive of environments.

This device is fully compatible with, and can be used to extend signals from, 4K USB 3.2 Gen 1 / 3.0 webcams and video conferencing systems.

For added convenience the Hybrid cable is bus-powered and is supplied with a USB Micro-B cable which can be attached to a second USB port should additional power be required.

Information about USB 3.0, 3.1 & 3.2

USB 3.0, USB 3.1 and USB 3.2 PCs, cables and devices are all compatible with each other, when using either a USB Type A or USB Type C host interface.
USB 3.0, USB 3.1 Gen 1 and USB 3.2 Gen 1 all support data transfer rates up to 5.

Connectors

    Connector A: USB Type A Male
    Connector B: USB Type A Female
    Power: USB Micro-B Female
    Housing Material: Metal
    Connector Plating: Nickel 80µ
    Pin Construction: Phosphor Copper
    Pin Plating: Gold 30µ
    Dimensions (approx.) WxDxH:
    USB A Male: 27x44x13mm (1.06x1.73x0.51in)
    USB A Female: 26x82x14mm (1.02x3.23x0.55in)


Cable Construction

    Length: 50m (164.04ft)
    Standard: USB 3.2 Gen 1 / USB 3.0
    Colour: Black
    Type: Round
    Jacket Diameter: 3.7mm (0.15in)
    Jacket Material: TPU
    Conductor Material: 2pcs Tinned Copper Wire / 2pcs Optical Fiber
    Conductor Gauge: 22AWG / OM1
    Shielding: PVC insulation material


Specifications

    Supported Bandwidth: 5Gbps
    Nominal Attenuation: -
    Minimum Bend Radius: 50mm (1.97in)
    Maximum Tensile Load: -
    Operating Temperature: 0°C - 50°C (32°F - 122°F)
    Storage Temperature: -20°C - 70°C (-4°F - 158°F)
    Transmission Medium: Optical Fiber
    Transmission Technology: -
