GOSSEN DISC Mastersix meter (u8-mastersix)

Technical data

• Measuring range : (with ISO 100/21°):
  Steady light LW -4 to +18
  Flashlight f/2,8 2/3 to 256
• Lightning synchronous times :
  1/1000, 1/500, 1/250, 1/125, 1/60, 1/30, 1/15, 1/8, 1/4, 1/2, 1 second
• Messwinkel : 30° steady light
  Messwinkel: 20° flashlight
• Blizlichtmenge :
  28,8 to 236000 Ixs
• Density of light (Lux -) and luminance measurement
• Order NR. : H02Å

• Measurement range LW -4 to 18 with ISO 100/21° (to LW 23 with measured value extension),
• Time 1/4000s to 8h,
• Screen 0.7 to 128,
• Lightning 2.8 to 45 (5 screen extension adjustably) dazzles,
• Film 1 to 800,000 ASP (1-60 DIN),
• Lightning synchronisation from 1/1000s to 1s,
• Korrekturfaktor +/- 7.9,
• Extension factor 1 to 239,
• Density 0.0 to 3 (with it one measures e.g. the density of negatives or filters),
• Density of light 0.175 to 700,000 lux, and/or 0.016 to 64,000 fc,
• Brilliance 0.007 to 28,000 cd/m2,
• Blitzlichmenge 28.8 to 7360 (236,000 with adjustable measuring range extension) lxs,
  2,7 to 684 (21,900 with schaltb. Measuring range extension) fcs,
• Messwinkel 30 degrees for steady light and 20 degrees for flashlight,
• Messwinkel with photometry with kalotte 180 degrees,
• Operating voltage over 9V compound battery.
